1.27mm Pitch Pin Header Connector SMD :RHTAY07CA

Series P/N: RHTAY07CA

Male pin header connetors & Mini jumper connectors is available at RHT.

We have been selling on the markets many years and get good feedback.

Please view our large selection of Male pin header connetors & Mini jumper connectors. Any questions,Please contact our sales team to get any service support.

If you need any samples,quick L/T, and etc, we will try our best to support.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

Features

-Mounting Type:Designed for surface-mounting on PCBs using reflow soldering processes. SMD pin headers feature solder tails or pads that adhere to the PCB surface, ensuring secure attachment and electrical connectivity.

-Current Rating:Rated for a range of current levels depending on the pin size, material, and configuration. SMD pin headers are suitable for low to moderate current applications typical in consumer electronics and industrial devices.

-Operating Temperature Range:Designed to operate within a specified temperature range, often from -40°C to +105°C or higher, ensuring suitability for various environmental conditions and applications.

-Customization:Can be customized in terms of pin length, plating thickness, insulator color, and other specifications to meet specific design requirements and application needs.

Applications

1. Test and Measurement Instruments

2. LED Lighting Systems

3. Security Systems

4. Audio-Visual Equipment

Specifications

1.27mm Pitch Pin Header Connector SMD

Order Information

RHTAY07CA-1.50-1-XX-PA*PC*PB-G0-W-R

Plastics Height:1.50、2.00、2.50mm

1-Single layer 2-Double layer

XX-Total pin number (No.of 2~80pin)
