5.08mm Male Pluggable terminal block:RHTBYDKFF-5.08

Features

-Pitch: 5.08mm pitch refers to the distance between each pin or terminal center, which is standard for many industrial applications.

-Gender: Male indicates that it has pins or contacts that can be inserted into a female connector.

-Termination Type:Usually designed for PCB (Printed Circuit Board) mounting with through-hole pins that are soldered to the PCB pads for a secure mechanical and electrical connection.

-Number of Pins: Available in various configurations such as single-row or double-row with multiple pins.

Applications

1. Consumer Electronics

2. Automotive Electronics

3. Renewable Energy

4. Medical Devices

Specifications

Electrical

Rated voltage: 300V

Rated current: 8A

Contact resistance: 20mΩ

Insulation resistance: 500MΩ/DC500V

Withstanding Voltage: AC2000V/1Min

Wire range: 28-16AWG 1.5mm²

Material

Contact: Brass,Sn Plated

Pin header: Brass, Tin plated

Housing: PA66, UL94V-0

Mechanical

Torque: 0.2Nm (2lb.in)

Strip length: 6-7mm

Technical Documents
